The recommended PCB layout for optimal thermal performance involves placing the DC-DC converter near a thermal vias or a heat sink, and ensuring good airflow around the component. A minimum of 1 inch of clearance around the converter is recommended.
To ensure EMC, it is recommended to follow proper PCB layout and grounding techniques, use a metal enclosure, and add EMI filters or shielding if necessary. Additionally, the VSK-S15-15U has built-in EMI filters, but external filtering may still be required depending on the application.
The VSK-S15-15U can drive a maximum capacitance load of 2200uF. Exceeding this value may cause instability or oscillation in the output voltage.
Yes, the VSK-S15-15U can be used in a redundant or parallel configuration to increase power output or improve reliability. However, it is recommended to consult with a CUI Inc. application engineer to ensure proper implementation.
The derating curve for the VSK-S15-15U at high temperatures is available upon request from CUI Inc. It is recommended to consult with a CUI Inc. application engineer to determine the suitable operating temperature range for a specific application.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
VSK-S15-15U Overview
Use the download button to access the VSK-S15-15U schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like VSK-S,
or try a keyword search, such as Power Supply Modules
