VTX-214-050-124 - VIGORTRONIX

VTX-214-050-124 Details

• Manufacturer Part Number:

  VTX-214-050-124

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  PACKAGE-4

• ECCN Code:

  EAR99

• Manufacturer:

  Vigortronix (UK) Ltd

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, C-UL-US, EN, IEC, UL

• Efficiency (Main Output):

  88%

• Input Voltage-Max:

  305 V

• Input Voltage-Min:

  90 V

• Input Voltage-Nom:

  115 V

• JESD-30 Code:

  R-XDMA-P4

• Length:

  74.2 mm

• Load Regulation-Max:

  2.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  2.083 A

• Output Voltage-Max:

  24.48 V

• Output Voltage-Min:

  23.52 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,4LEAD,2.4

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER VOLTAGE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.084 Vrms

• Screening Level:

  EN/IEC/UL 62368-1

• Seated Height-Max:

  23.1 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  50 W

• Trim/Adjustable Output:

  NO

• Width:

  47 mm
