VXR100-281515D - VPT

VXR100-281515D Details

• Manufacturer Part Number:

  VXR100-281515D

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan, USA

• ECCN Code:

  EAR99

• Date Of Intro:

  2018-05-30

• Manufacturer:

  VPT Inc

• YTEOL:

  6

• Additional Feature:

  -15 ADDITIONAL OUTPUT IS AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  89%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  11 V

• Input Voltage-Nom:

  28 V

• JESD-30 Code:

  R-MDFM-P11

• Line Regulation-Max:

  0.003%

• Load Regulation-Max:

  0.13333%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  11

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  3.3 A

• Output Voltage-Max:

  16.5 V

• Output Voltage-Min:

  12 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  METAL

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Protections:

  SHORT CIRCUIT; OUTPUT OVER VOLTAGE

• Ripple Voltage (Main Out):

  0.038885 Vrms

• Surface Mount:

  NO

• Switching Frequency-Max:

  550 kHz

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  100 W

• Trim/Adjustable Output:

  YES
