VXR30-2805S - VPT Inc

VXR30-2805S Details

• Manufacturer Part Number:

  VXR30-2805S

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan, USA

• ECCN Code:

  EAR99

• Manufacturer:

  VPT Inc

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  88%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  28 V

• JESD-30 Code:

  R-PDFM-P10

• Length:

  43.18 mm

• Line Regulation-Max:

  0.0005%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  6 A

• Output Voltage-Max:

  5.5 V

• Output Voltage-Min:

  4.94 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Protections:

  SHORT CIRCUIT; OUTPUT OVERCURRENT; INPUT UNDER VOLTAGE

• Ripple Voltage (Main Out):

  0.02121 Vrms

• Seated Height-Max:

  9.14 mm

• Surface Mount:

  NO

• Switching Frequency-Max:

  550 kHz

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  30 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.01 s

• Width:

  33.02 mm
