VXR30-281515D - VPTPOWER

VXR30-281515D Details

• Manufacturer Part Number:

  VXR30-281515D

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan, USA

• ECCN Code:

  EAR99

• Manufacturer:

  VPT Inc

• YTEOL:

  8

• Additional Feature:

  ALSO HAVE A ADDITIONAL 15 V OUTPUT

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  85%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  28 V

• JESD-30 Code:

  R-PDMA-P9

• Length:

  43.18 mm

• Line Regulation-Max:

  0.0015%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  9

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Output Voltage-Max:

  15.38 V

• Output Voltage-Min:

  14.62 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OUTPUT OVER CURRENT

• Ripple Voltage (Main Out):

  0.0194425 Vrms

• Seated Height-Max:

  9.14 mm

• Surface Mount:

  NO

• Switching Frequency-Max:

  550 kHz

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  30 W

• Trim/Adjustable Output:

  NO

• Width:

  33.02 mm
