The recommended land pattern for the VY1471K31Y5UQ63V0 can be found in the Vishay Intertechnologies' application note AN48374, which provides guidelines for PCB layout and land pattern design.
The VY1471K31Y5UQ63V0 has a thermal resistance of 2.5°C/W. To ensure proper thermal management, it is recommended to use a heat sink or a thermal interface material with a thermal conductivity of at least 1 W/m-K. Additionally, ensure good airflow around the component and avoid blocking the airflow with other components or obstacles.
The VY1471K31Y5UQ63V0 has an operating temperature range of -40°C to 150°C. However, it is recommended to derate the component's power rating at higher temperatures to ensure reliable operation.
To ensure the reliability of the VY1471K31Y5UQ63V0 in high-vibration environments, it is recommended to use a secure mounting method, such as screwing or adhesive bonding, and to ensure that the component is properly secured to the PCB. Additionally, consider using a vibration-dampening material or a shock-absorbing mount to reduce the impact of vibrations on the component.
The VY1471K31Y5UQ63V0 should be stored in a dry, cool place, away from direct sunlight and moisture. Handle the component by the body, avoiding touching the leads or electrical contacts. Use anti-static packaging and handling procedures to prevent electrostatic discharge damage.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
VY1471K31Y5UQ63V0 Overview
Use the download button to access the VY1471K31Y5UQ63V0 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like VY147,
or try a keyword search, such as Ceramic Capacitors
