W06G - HY Electronic

W06G Details

• Manufacturer Part Number:

  W06G

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  HY Electronic Corp

• Breakdown Voltage-Min:

  600 V

• Configuration:

  BRIDGE, 4 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  BRIDGE RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.1 V

• JESD-30 Code:

  O-PBCY-W4

• Non-rep Pk Forward Current-Max:

  50 A

• Number of Elements:

  4

• Number of Phases:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  1.5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  CYLINDRICAL

• Rep Pk Reverse Voltage-Max:

  600 V

• Reverse Current-Max:

  10 µA

• Reverse Test Voltage:

  600 V

• Surface Mount:

  NO

• Terminal Form:

  WIRE

• Terminal Position:

  BOTTOM
