W681360RG - Nuvoton

W681360RG Details

• Manufacturer Part Number:

  W681360RG

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SSOP-20

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Nuvoton Technology Corp

• YTEOL:

  6.05

• Companding Law:

  MU-LAW

• Filter:

  YES

• Gain Tolerance-Max:

  0.2 dB

• Input Code:

  TWOS COMPLEMENT

• Input Type:

  DIFFERENTIAL

• JESD-30 Code:

  R-PDSO-G20

• Length:

  7.2 mm

• Linear Coding:

  13-BIT

• Moisture Sensitivity Level:

  3

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  20

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output:

  VOLTAGE

• Output Code:

  TWOS COMPLEMENT

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SSOP

• Package Equivalence Code:

  SSOP20,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, SHRINK PITCH

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2 mm

• Supply Current-Max:

  0.0047 mA

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Telecom IC Type:

  PCM CODEC

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Width:

  5.3 mm
