WM8213SCDS/V - Cirrus Logic

Description: Analog Front End - AFE 16-Bit 24MSPS 3-Channel AFE

Download WM8213SCDS/V Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
WM8213SCDS/V - Cirrus Logic PCB footprint - Small Outline Packages - Small Outline Packages - SSOP28
click to zoom
3D Models
WM8213SCDS/V - Cirrus Logic  - 3D model - Small Outline Packages - SSOP28
click to zoom

WM8213SCDS/V Details

  • Manufacturer Part Number:

    WM8213SCDS/V

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Cirrus Logic

  • YTEOL:

    0

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    R-PDSO-G28

  • Length:

    10.2 mm

  • Number of Functions:

    1

  • Number of Terminals:

    28

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, SHRINK PITCH

  • Seated Height-Max:

    2 mm

  • Supply Voltage-Max (Vsup):

    3.63 V

  • Supply Voltage-Min (Vsup):

    2.97 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    COMMERCIAL

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    5.3 mm

WM8213SCDS/V Frequently Asked Questions (FAQs)

  • The recommended layout and routing for the WM8213SCDS/V can be found in the Cirrus Logic application note AN215, which provides guidelines for PCB layout, component placement, and routing to ensure optimal performance and minimize noise.
  • To optimize the WM8213SCDS/V for low power consumption, ensure that the device is operated in the correct power mode (e.g., idle or shutdown) when not in use, and adjust the clock frequency and voltage regulator settings according to the application's requirements. Additionally, consider using the device's built-in power-saving features, such as dynamic voltage and frequency scaling.
  • The WM8213SCDS/V has a maximum junction temperature of 150°C. To ensure reliable operation, it is essential to provide adequate thermal management, such as using a heat sink or thermal pad, and ensuring good airflow around the device. The thermal resistance of the package (θJA) is approximately 25°C/W.
  • To troubleshoot issues with the WM8213SCDS/V, start by consulting the datasheet and application notes for guidance on common issues and solutions. Use oscilloscopes and logic analyzers to debug the device's signals and verify that the device is receiving the correct clock and control signals. Additionally, check the power supply and decoupling capacitors to ensure they are functioning correctly.
  • To minimize electromagnetic interference (EMI) and radio-frequency interference (RFI) with the WM8213SCDS/V, ensure that the device is properly shielded, and use EMI filters and shielding on the PCB. Additionally, follow good PCB design practices, such as separating analog and digital signals, and using ground planes to reduce noise.
