XCL220B2L3FR-G - Torex

XCL220B2L3FR-G Details

• Manufacturer Part Number:

  XCL220B2L3FR-G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Torex Semiconductor LTD

• YTEOL:

  0

• Additional Feature:

  ALSO REQUIRE PFM CONTROL TECHNIQUE

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  VOLTAGE-MODE

• Control Technique:

  PULSE WIDTH MODULATION

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  2.5 V

• Input Voltage-Nom:

  4.75 V

• JESD-30 Code:

  R-XBCC-B8

• Length:

  2.5 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1 A

• Output Voltage-Max:

  2.907 V

• Output Voltage-Min:

  2.793 V

• Output Voltage-Nom:

  2.85 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  BCC

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  1.04 mm

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK

• Switching Frequency-Max:

  3000 kHz

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Nickel/Silver/Gold (Ni/Ag/Au)

• Terminal Form:

  BUTT

• Terminal Pitch:

  0.55 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  10

• Width:

  2 mm
