XCL232D201KR-G - Torex

XCL232D201KR-G Details

• Manufacturer Part Number:

  XCL232D201KR-G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CL-2025, 6 PIN

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Torex Semiconductor LTD

• YTEOL:

  10

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  VOLTAGE-MODE

• Control Technique:

  PULSE FREQUENCY MODULATION

• Input Voltage-Max:

  6 V

• Input Voltage-Min:

  1.8 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-PDSO-N6

• Length:

  2.5 mm

• Number of Functions:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.15 A

• Output Voltage-Max:

  2.04 V

• Output Voltage-Min:

  1.96 V

• Output Voltage-Nom:

  2 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HSON

• Package Equivalence Code:

  SOLCC6,.08,22

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG

• Seated Height-Max:

  1.04 mm

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.55 mm

• Terminal Position:

  DUAL

• Width:

  2 mm
