Z86E0812PSC - LITTELFUSE

Z86E0812PSC Details

• Manufacturer Part Number:

  Z86E0812PSC

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-18

• HTS Code:

  8542.31.00.15

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  4.5

• Has ADC:

  NO

• Additional Feature:

  OPTIONAL LOW EMI MODE; EPROM PROTECT; TWO STANDBY MODES

• Bit Size:

  8

• Boundary Scan:

  NO

• CPU Family:

  Z8

• Clock Frequency-Max:

  12 MHz

• DAC Channels:

  NO

• DMA Channels:

  NO

• Format:

  FIXED POINT

• Integrated Cache:

  NO

• JESD-30 Code:

  R-PDIP-T18

• JESD-609 Code:

  e0

• Length:

  22.86 mm

• Low Power Mode:

  YES

• Number of External Interrupts:

  6

• Number of I/O Lines:

  14

• Number of Terminals:

  18

• Number of Timers:

  2

• On Chip Data RAM Width:

  8

• On Chip Program ROM Width:

  8

• Operating Temperature-Max:

  70 °C

• PWM Channels:

  NO

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP18,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  240

• Qualification Status:

  Not Qualified

• RAM (bytes):

  125

• RAM (words):

  124

• ROM (words):

  2048

• ROM Programmability:

  OTPROM

• Seated Height-Max:

  4.24 mm

• Speed:

  12 MHz

• Supply Current-Max:

  15 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  7.62 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER
