ZB1021-ALD - COILCRAFT

ZB1021-ALD Details

• Manufacturer Part Number:

  ZB1021-ALD

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  6

• Additional Feature:

  HEIGHT DIM INCLUDE TERMINAL ALSO

• Height:

  11 mm

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  17 V

• JESD-609 Code:

  e1

• Length:

  12.7 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Primary Winding:

  1

• Number of Secondary Winding:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage 1:

  5 V

• Packing Method:

  TR, EMBOSSED PLASTIC, 13 INCH

• Power Rating:

  7.5 W

• Primary Inductance:

  22 µH

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Transformer Type:

  SMPS TRANSFORMER

• Width:

  10.5 mm
