ZN416E - Microsemi Corporation

ZN416E Details

• Manufacturer Part Number:

  ZN416E

• Rohs Code:

  No

• Part Life Cycle Code:

  Obsolete

• Package Description:

  DIP,

• Reach Compliance Code:

  Unknown

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Microsemi Corporation (now Microchip)

• YTEOL:

  0

• Consumer IC Type:

  AUDIO SINGLE CHIP RECEIVER

• Demodulation Type:

  AM

• Harmonic Distortion:

  3%

• JESD-30 Code:

  R-PDIP-T8

• JESD-609 Code:

  e0

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  70 °C

• Output Voltage-Nom (AM):

  120 mV

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• Supply Voltage-Max (Vsup):

  1.6 V

• Supply Voltage-Min (Vsup):

  1.1 V

• Surface Mount:

  NO

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL
