0857271002 - Molex

Description: Gigabit Magnetic Jack 2X4, LEDs Green and Orange/Green

Download 0857271002 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
0857271002 - Molex - PCB symbol
click to zoom
PCB Footprints
0857271002 - Molex PCB footprint - Other - Other - 0857271002
click to zoom
3D Models
0857271002 - Molex - 3D model - Other - 0857271002
click to zoom

0857271002 Details

  • Manufacturer Part Number:

    0857271002

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.69.40.30

  • Manufacturer:

    Molex

  • Connector Type:

    TELECOM AND DATACOM CONNECTOR

  • Contact Finish Mating:

    NOT SPECIFIED

  • Contact Finish Termination:

    Tin (Sn)

  • Contact Material:

    NOT SPECIFIED

  • JESD-609 Code:

    e3

0857271002 Frequently Asked Questions (FAQs)

  • The recommended mating sequence for the 0857271002 connector is to mate the guide pins first, followed by the signal pins. This ensures proper alignment and prevents damage to the connector.
  • Yes, the 0857271002 connector is designed to withstand high-vibration environments. However, it's essential to follow proper mounting and fastening procedures to ensure the connector remains secure.
  • The maximum cable bend radius for the 0857271002 connector is 25 mm (1 inch). Exceeding this radius may cause damage to the cable or connector.
  • The 0857271002 connector is designed to operate in a temperature range of -40°C to 105°C (-40°F to 221°F) and can withstand humidity up to 95%. However, it's essential to follow proper sealing and protection procedures to ensure the connector remains reliable in harsh environments.
  • The 0857271002 connector is designed for use with specific cable types and sizes. Using a different cable type or size may affect the connector's performance and reliability. It's recommended to consult with Molex or a qualified engineer to determine the compatibility of the connector with your specific cable requirements.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

0857271002 Overview

Use the download button to access the 0857271002 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like 08572, or try a keyword search, such as Telecom and Datacom Connectors

About Molex

Molex is a global manufacturer of connectivity solutions for various industries. The company offers a wide range of products including connectors, cables, antennas, sensors, and integrated systems. Molex's products are used in diverse applications such as automotive, telecommunications, data centers, consumer electronics, industrial automation, medical devices, and aerospace.
