1-1393277-8 - TE Connectivity

1-1393277-8 Details

• Manufacturer Part Number:

  1-1393277-8

• Brand Name:

  CII

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.05

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  TE Connectivity

• YTEOL:

  5.49

• Body Breadth:

  21.1 mm

• Body Height:

  21.2 mm

• Body Length or Diameter:

  26.1 mm

• Coil Current(DC)-Max:

  0.066 A

• Coil Operate Voltage(DC):

  14.1 V

• Coil Power:

  1600 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  362 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  30A@12VAC

• Contact Current(AC)-Max:

  30 A

• Contact Current(DC)-Max:

  45 A

• Contact (DC) Max Rating R Load:

  45A@12VDC

• Contact Voltage(AC)-Max:

  12 V

• Contact Voltage(DC)-Max:

  12 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  200000 Cycle(s)

• JESD-609 Code:

  e3

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  5 ms

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BULK

• Physical Dimension:

  26.1mm x 21.1mm x 21.2mm

• Reference Standard:

  EIA; EN; IEC

• Relay Action:

  MOMENTARY

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  3 ms

• Sealing:

  RT3

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Termination Type:

  SOLDER
