10-32-1101 - Molex

10-32-1101 Details

• Manufacturer Part Number:

  10-32-1101

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  19 Weeks

• Manufacturer:

  Molex

• YTEOL:

  0

• Body Breadth:

  0.402 inch

• Body Depth:

  0.508 inch

• Body Length:

  1.957 inch

• Connector Type:

  BOARD CONNECTOR

• Contact Arrangement:

  S0P10

• Contact Finish Mating:

  SN ON CU

• Contact Finish Termination:

  TIN

• Contact Gender:

  MALE

• Contact Material:

  BRASS

• Contact Resistance:

  10 mΩ

• Contact Style:

  SQ PIN-SKT

• Dielectric Withstanding Voltage:

  2100VAC V

• Durability:

  30 Cycles

• Filter Feature:

  NO

• Insulation Resistance:

  1000000000 Ω

• Insulator Color:

  NATURAL

• Insulator Material:

  POLYAMIDE

• Mixed Contacts:

  YES

• Mounting Option 1:

  LOCKING

• Mounting Option 2:

  FRICTION LOCK

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Plating Thickness:

  200u inch

• Reference Standard:

  UL,CSA,TUV

• Terminal Length:

  0.142 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  10
