122490RP - Amphenol

122490RP Details

• Manufacturer Part Number:

  122490RP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  8

• Additional Feature:

  INSERTION LOSS MAX AT: 9GHZ

• Body/Shell Style:

  JACK

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF TNC CONNECTOR

• Contact Gender:

  FEMALE

• Contact Resistance:

  1.5 mΩ

• Contact Style:

  COAX

• Coupling Type:

  THREADED

• Dielectric Withstanding Voltage:

  1500VAC V

• Durability:

  500 Cycles

• Filter Feature:

  NO

• Insertion Loss:

  0.18 dB

• Insulation Resistance:

  5000000000 Ω

• Insulator Color:

  NATURAL

• Insulator Material:

  POLYTETRAFLUOROETHYLENE

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Frequency-Max:

  11 GHz

• Operating Temperature-Max:

  165 °C

• Operating Temperature-Min:

  -65 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Shell Finish:

  NICKEL

• Shell Material:

  BRASS

• Terminal Length:

  0.118 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.3
