12VR1S20F4N103B1 - CTS

12VR1S20F4N103B1 Details

• Manufacturer Part Number:

  12VR1S20F4N103B1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8533.40.80.70

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  CTS Corporation

• YTEOL:

  6

• Actuator Orientation:

  HORIZONTAL

• Actuator Type:

  SHAFT

• Construction:

  Threaded Bushing

• Ganging Number:

  1

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  5

• Number of Turns:

  1

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -10 °C

• Package Height:

  13.2 mm

• Package Length:

  12.4 mm

• Package Style:

  PCB Mount

• Package Width:

  7.4 mm

• Packing Method:

  TRAY

• Rated Power Dissipation (P):

  0.05 W

• Resistance:

  10000 Ω

• Resistance Law:

  LINEAR

• Resistor Type:

  POTENTIOMETER

• Rotational Angle:

  300 deg

• Surface Mount:

  NO

• Technology:

  CARBON COMPOSITION

• Terminal Shape:

  FLAT

• Tolerance:

  20%

• Working Voltage:

  10 V
