13-000021 - CONEC

13-000021 Details

• Manufacturer Part Number:

  13-000021

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Conec Corporation

• Additional Feature:

  DESIGN 7W2/7W2

• Body Breadth:

  1.02 inch

• Body Depth:

  0.615 inch

• Body Length:

  1.544 inch

• Contact Finish Mating:

  AU ON NI

• Contact Finish Termination:

  GOLD OVER NICKEL

• Contact Gender:

  MALE

• Contact Material:

  COPPER ALLOY

• Contact Resistance:

  8 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  1000VDC V

• Insulator Color:

  GREEN

• Insulator Material:

  GLASS FILLED POLYBUTYLENE TEREPHTHALATE

• Mixed Contacts:

  YES

• Mounting Option 1:

  #4-40

• Mounting Option 2:

  THREADED INSERT

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  TWO

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Plating Thickness:

  30u inch

• Rated Current (Signal):

  7.5 A

• Reference Standard:

  UL,VDE,CSA

• Shell Finish:

  TIN

• Shell Material:

  STEEL

• Terminal Length:

  0.142 inch

• Termination Type:

  SOLDER
