1410605C - Murata Electronics

1410605C Frequently Asked Questions (FAQs)

• What is the recommended land pattern for the 1410605C?
  Murata recommends a land pattern with a pad size of 1.3mm x 0.8mm, with a non-solder mask defined (NSMD) pad shape, and a minimum clearance of 0.2mm between the pad and the solder mask.
• Can I use the 1410605C in a high-temperature environment?
  The 1410605C is rated for operation up to 125°C, but it's recommended to derate the component's performance at high temperatures. Consult Murata's reliability handbook for more information on temperature derating.
• How do I handle the 1410605C during PCB assembly to prevent damage?
  Handle the component by the edges, avoid touching the pads, and use an anti-static wrist strap or mat to prevent electrostatic discharge (ESD) damage. Follow standard PCB assembly and handling procedures.
• What is the recommended soldering profile for the 1410605C?
  Murata recommends a soldering profile with a peak temperature of 260°C, a dwell time above 220°C of 30-60 seconds, and a cooling rate of 3-5°C/second. Consult Murata's soldering guidelines for more information.
• Can I use the 1410605C in a high-vibration environment?
  The 1410605C is designed to withstand moderate vibration, but it's recommended to consult Murata's vibration testing guidelines and perform additional testing to ensure the component meets your specific application requirements.
