15311R-1000 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  Renesas recommends a 4-layer PCB with a solid ground plane and thermal vias to dissipate heat efficiently. A minimum of 2 oz copper thickness is recommended for the top and bottom layers.
• How do I ensure reliable operation in high-temperature environments?
  Renesas recommends using a heat sink with a thermal resistance of 10°C/W or lower, and ensuring good airflow around the device. Additionally, consider using a thermal interface material with a thermal conductivity of 1 W/m-K or higher.
• What is the recommended input capacitor value and type for the 15311R-1000?
  Renesas recommends using a 10uF to 22uF X7R or X5R ceramic capacitor with a voltage rating of 25V or higher, placed as close to the VIN pin as possible.
• How do I optimize the output filter design for the 15311R-1000?
  Renesas recommends using a 2nd-order LC filter with a 1uH inductor and a 10uF capacitor, and placing the filter components as close to the output pin as possible. The filter should be designed to attenuate noise above 100 kHz.
• What is the recommended startup sequence for the 15311R-1000?
  Renesas recommends applying the input voltage (VIN) first, followed by the enable signal (EN). The output voltage (VOUT) should be monitored to ensure it reaches the desired level before connecting the load.
