163A17379X - CONEC

163A17379X Details

• Manufacturer Part Number:

  163A17379X

• Part Life Cycle Code:

  Active Unconfirmed

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Conec Corporation

• YTEOL:

  2

• Additional Feature:

  STAMPED CNTS & GND INDENT

• Body Breadth:

  0.509 inch

• Body Depth:

  0.276 inch

• Body Length:

  1.228 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  D SUBMINIATURE CONNECTOR

• Contact Design:

  PREASSEM CONN

• Contact Finish Mating:

  AU ON NI

• Contact Gender:

  MALE

• Contact Material:

  COPPER ALLOY

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  10 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  1000VAC V

• Insertion Force-Max:

  3.336 N

• Insulation Resistance:

  5000000000 Ω

• Insulator Material:

  GLASS FILLED POLYESTER

• Mounting Option 1:

  HOLE .112-.124

• Mounting Type:

  PANEL

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Rated Current (Signal):

  5 A

• Reference Standard:

  UL

• Shell Finish:

  TIN

• Shell Material:

  STEEL

• Terminal Length:

  0.075 inch

• Termination Type:

  SOLDER LUG

• Total Number of Contacts:

  9

• Wire Size-Max:

  20 AWG

• Wire Size-Min:

  20 AWG

• Withdrawl Force-Min:

  3.336 N
