A good PCB layout for the 1646W16-U involves keeping the input and output traces short and symmetrical, using a solid ground plane, and placing decoupling capacitors close to the device. THAT Corporation provides a recommended PCB layout in their application notes.
Proper biasing of the 1646W16-U involves setting the voltage on the VREF pin to the desired level, typically between 1.2V and 3.6V. The voltage on the VCC pin should be set to the same voltage as the system's power supply. THAT Corporation provides a detailed biasing scheme in their application notes.
The maximum power dissipation of the 1646W16-U is 500mW. It's essential to ensure that the device is properly heat-sinked and that the ambient temperature is within the recommended operating range to prevent overheating.
The 1646W16-U is rated for operation up to 85°C. However, for high-temperature applications above 85°C, THAT Corporation recommends using the 1646W16-HT, which is specifically designed for high-temperature operation up to 125°C.
Common issues with the 1646W16-U can be troubleshooted by checking the PCB layout, ensuring proper biasing, and verifying that the input and output impedances are matched. THAT Corporation provides a troubleshooting guide in their application notes, which includes a checklist of common issues and their solutions.
