16SVPB33M - Panasonic

16SVPB33M Details

• Manufacturer Part Number:

  16SVPB33M

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00.20

• Factory Lead Time:

  26 Weeks

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  0

• Additional Feature:

  ESR IS MEASURED AT 100KHZ TO 300KHZ

• Capacitance:

  33 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  6.3 mm

• Dielectric Material:

  ALUMINUM (SOLID POLYMER)

• ESR:

  40 mΩ

• Height:

  4.9 mm

• Leakage Current:

  0.211 mA

• Length:

  6.6 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Package Shape:

  CYLINDRICAL PACKAGE

• Package Style:

  SMT

• Packing Method:

  TR, EMBOSSED, 15 INCH

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  16 V

• Ripple Current:

  83.5 mA

• Size Code:

  2626

• Surface Mount:

  YES

• Tan Delta:

  0.12

• Terminal Shape:

  FLAT

• Width:

  6.6 mm
