1720602 - Phoenix Contact

1720602 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, depending on the specific application and PCB material. It's essential to consult the Phoenix Contact application notes for specific guidance.
• Can I use this connector in a high-vibration environment?
  Yes, the 1720602 connector is designed to withstand vibrations up to 10 g according to IEC 60068-2-6. However, it's crucial to ensure proper mounting and screwing to prevent loosening or damage.
• Is the connector suitable for use in harsh environments, such as those with high humidity or extreme temperatures?
  The 1720602 connector is rated for operation in temperatures ranging from -40°C to 125°C and can withstand humidity up to 95% RH. However, it's essential to consult the datasheet and Phoenix Contact's environmental specifications for specific guidance.
• Can I use this connector with wire sizes other than the recommended AWG 20-24?
  While the connector is designed for AWG 20-24 wires, it's possible to use smaller or larger wires with proper wire preparation and strain relief. However, this may affect the connector's performance and reliability. Consult Phoenix Contact's application notes for guidance on wire size and preparation.
• Are there any specific PCB layout considerations I should be aware of when using this connector?
  Yes, it's essential to follow Phoenix Contact's recommended PCB layout guidelines to ensure proper connector mating and to prevent damage to the PCB or connector. This includes maintaining a minimum clearance of 1.5 mm around the connector and avoiding vias or tracks under the connector.
