1821300 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a PCB?
  The recommended torque is 0.5 Nm to 1.5 Nm, depending on the specific application and PCB material. It's essential to consult the Phoenix Contact application notes for more detailed guidance.
• Can I use this connector in high-vibration or high-shock environments?
  Yes, the 1821300 connector is designed to withstand vibrations and shocks. However, it's crucial to ensure proper mounting and screwing to prevent damage. Phoenix Contact recommends following their guidelines for vibration and shock testing.
• Is the connector suitable for use in harsh environments, such as high temperatures or humidities?
  The 1821300 connector is rated for operating temperatures between -40°C and 125°C, and can withstand humidities up to 95%. However, it's essential to consider the specific environmental conditions of your application and consult Phoenix Contact's environmental testing guidelines.
• Can I use this connector with wire sizes other than the recommended AWG 20-24?
  While the connector is optimized for AWG 20-24 wires, it's possible to use other wire sizes. However, this may affect the connector's performance and reliability. Consult Phoenix Contact's wire size guidelines and perform thorough testing before using non-recommended wire sizes.
• How do I ensure proper mating and unmating of the connector?
  To ensure proper mating and unmating, follow Phoenix Contact's guidelines for connector handling and mating/unmating forces. It's essential to apply the recommended mating force and avoid excessive force, which can damage the connector or PCB.
