1920969 - Phoenix Contact

1920969 Frequently Asked Questions (FAQs)

• What is the recommended torque for screwing the connector onto a panel?
  The recommended torque is 0.6 Nm to 1.2 Nm, depending on the specific application and panel material. It's essential to consult the installation instructions and follow the recommended torque to ensure a secure connection.
• Can I use this connector in a high-vibration environment?
  Yes, the 1920969 connector is designed to withstand vibrations and shocks. It meets the requirements of IEC 61373 Category 2, which means it can operate in environments with vibrations up to 15 g (147 m/s²) and shocks up to 30 g (294 m/s²). However, it's crucial to ensure proper installation and secure fastening to maintain the connector's integrity.
• Is the connector suitable for outdoor use or exposure to harsh environmental conditions?
  The 1920969 connector has a protection rating of IP67, which means it can withstand temporary immersion in water up to 1 meter for 30 minutes. It's also designed to operate in temperatures ranging from -40°C to 100°C. However, it's essential to consider additional protection measures, such as conformal coating or potting, for extreme environmental conditions.
• Can I use this connector with a different wire gauge or type than recommended?
  While it's technically possible to use a different wire gauge or type, it's not recommended. The 1920969 connector is designed to work with specific wire gauges and types, as specified in the datasheet. Using a different wire gauge or type may compromise the connector's performance, reliability, and safety. It's essential to follow the recommended specifications to ensure a reliable connection.
• How do I ensure proper wire termination and strain relief?
  To ensure proper wire termination and strain relief, follow the recommended wire stripping and termination procedures. Use the correct wire stripping tool to remove the insulation, and then insert the wire into the connector's wire clamp. Make sure to secure the wire with the wire clamp and apply the recommended torque. Additionally, use a strain relief method, such as a cable tie or clamp, to prevent wire damage and ensure a secure connection.
