1N2804A - Microsemi Corporation

1N2804A Details

• Manufacturer Part Number:

  1N2804A

• Pbfree Code:

  No

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  TO-3

• Package Description:

  TO-3, 2 PIN

• Pin Count:

  2

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Microsemi Corporation (now Microchip)

• Case Connection:

  ANODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  ZENER DIODE

• JEDEC-95 Code:

  TO-204AD

• JESD-30 Code:

  O-MBFM-P2

• JESD-609 Code:

  e0

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  METAL

• Package Shape:

  ROUND

• Package Style:

  FLANGE MOUNT

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  50 W

• Qualification Status:

  Not Qualified

• Reference Voltage-Nom:

  6.8 V

• Surface Mount:

  NO

• Technology:

  ZENER

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  PIN/PEG

• Terminal Position:

  BOTTOM

• Voltage Tol-Max:

  10%

• Working Test Current:

  1850 mA
