1N4744A-TAP - Vishay

1N4744A-TAP Details

• Manufacturer Part Number:

  1N4744A-TAP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  5

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  ZENER DIODE

• JEDEC-95 Code:

  DO-41

• JESD-30 Code:

  O-XALF-W2

• JESD-609 Code:

  e2

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  1.3 W

• Qualification Status:

  Not Qualified

• Reference Voltage-Nom:

  15 V

• Surface Mount:

  NO

• Technology:

  ZENER

• Terminal Finish:

  Tin/Silver (Sn96.5Ag3.5)

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Voltage Tol-Max:

  5%

• Working Test Current:

  17 mA
