1N5925APe3/TR8 - Microchip

1N5925APe3/TR8 Details

• Manufacturer Part Number:

  1N5925APE3/TR8

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  0

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  ZENER DIODE

• Dynamic Impedance-Max:

  4.5 Ω

• JEDEC-95 Code:

  DO-204AL

• JESD-30 Code:

  O-PALF-W2

• Knee Impedance-Max:

  500 Ω

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  1.5 W

• Reference Standard:

  MIL-STD-750

• Reference Voltage-Nom:

  10 V

• Reverse Current-Max:

  5 µA

• Reverse Test Voltage:

  8 V

• Surface Mount:

  NO

• Technology:

  ZENER

• Terminal Finish:

  Matte Tin (Sn) - with Copper (Cu) barrier

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL

• Voltage Tol-Max:

  10%

• Working Test Current:

  37.5 mA
