1N914TR - onsemi

1N914TR Details

• Manufacturer Part Number:

  1N914TR

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  Axial Lead

• Manufacturer Package Code:

  017AG

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.70

• Manufacturer:

  onsemi

• YTEOL:

  5.78

• Application:

  GENERAL PURPOSE

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1 V

• JEDEC-95 Code:

  DO-35

• JESD-30 Code:

  O-XALF-W2

• JESD-609 Code:

  e3

• Non-rep Pk Forward Current-Max:

  2 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Output Current-Max:

  0.2 A

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Power Dissipation-Max:

  0.5 W

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  100 V

• Reverse Recovery Time-Max:

  0.004 µs

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL
