2007435-1 - TE Connectivity

2007435-1 Details

• Manufacturer Part Number:

  2007435-1

• Brand Name:

  TE Connectivity

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.7

• Board Mounting Option:

  LOCATING POST

• Body Breadth:

  0.646 inch

• Body Depth:

  0.909 inch

• Body Length:

  0.303 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  HDMI CONNECTOR

• Contact Design:

  PREASSEM CONN

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT APPLICABLE

• Contact Resistance:

  20 mΩ

• Contact Style:

  USB SER A FLAT

• DIN Conformance:

  NO

• Durability:

  10000 Cycles

• EMI Shielded:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulation Resistance:

  10000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYETHYLENE

• MIL Conformance:

  NO

• Mains Connector Rating:

  .5A

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  2

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  1.0922 mm

• Panel Mount:

  NO

• Plating Thickness:

  15u inch

• Polarization Key:

  POLARIZED KEY

• Rated Current (Signal):

  0.5 A

• Reference Standard:

  UL

• Shell Finish:

  TIN

• Shell Material:

  STAINLESS STEEL

• Terminal Length:

  0.091 inch

• Terminal Pitch:

  1 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  19

• UL Flammability Code:

  94V-0
