2007562-6 - TE Connectivity

Description: SFP+, Cage Assembly with Integrated Connector, .032in [.8mm] Centerline, Signal, Operating Temperature Range -55 – 105 °C [-67 – 221 °F]

Download 2007562-6 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
2007562-6 - TE Connectivity - PCB symbol
click to zoom
PCB Footprints
2007562-6 - TE Connectivity PCB footprint - Other - Other - 2007562-6-2
click to zoom
3D Models
2007562-6 - TE Connectivity - 3D model - Other - 2007562-6-2
click to zoom

2007562-6 Details

  • Manufacturer Part Number:

    2007562-6

  • Brand Name:

    TE Connectivity

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Reach Compliance Code:

    Unknown

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.69.40.30

  • Manufacturer:

    TE Connectivity

  • YTEOL:

    6.78

  • Connector Type:

    SFP CONNECTOR

  • Contact Finish Mating:

    NOT APPLICABLE

  • Contact Material:

    NOT APPLICABLE

  • DIN Conformance:

    NO

  • EMI Shielded:

    NO

  • Empty Shell:

    YES

  • Filter Feature:

    NO

  • IEC Conformance:

    NO

  • MIL Conformance:

    NO

  • Mains Connector Rating:

    115/230VAC

  • Mixed Contacts:

    NO

  • Mounting Type:

    BOARD

  • Number Of Connectors:

    ONE

  • Number of Ports:

    12

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -55 °C

  • Option:

    GENERAL PURPOSE

  • Panel Mount:

    NO

  • Reference Standard:

    UL

  • Terminal Length:

    0.118 inch

  • Terminal Pitch:

    0.8 mm

  • Termination Type:

    PRESS FIT

  • Total Number of Contacts:

    240

  • UL Flammability Code:

    94V-0

2007562-6 Frequently Asked Questions (FAQs)

  • The recommended torque value for the screw terminals is 0.5-1.5 Nm (4.4-13.3 in-lbs). It's essential to follow this range to ensure reliable connections and prevent damage to the connector.
  • Yes, the 2007562-6 connector is designed to withstand vibrations up to 10G (10 Hz to 2000 Hz) according to IEC 61373 Cat. 2. However, it's crucial to ensure proper mounting and secure the connector to the PCB or chassis to maintain reliability.
  • The 2007562-6 connector is rated for operation in temperatures ranging from -40°C to 125°C (-40°F to 257°F). It's essential to consider the temperature range of your application to ensure the connector's reliability and performance.
  • The 2007562-6 connector has a IP67 rating, which means it can withstand temporary immersion in water up to 1 meter (3.3 feet) for 30 minutes. However, it's not designed for continuous exposure to harsh chemicals or extreme environmental conditions. Additional protection or sealing may be required for such applications.
  • The 2007562-6 connector is designed for use with 20-24 AWG wire. Using a different wire gauge or type may affect the connector's performance and reliability. It's recommended to consult with TE Connectivity or a qualified engineer to ensure compatibility and proper termination.
