206-5 - CTS

Description: Dip Switch SPST 5 Position Through Hole Slide (Standard) Actuator 50mA 24VDC

Download 206-5 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
206-5 - CTS PCB footprint - Other - Other - 206-5-7
click to zoom
3D Models
206-5 - CTS  - 3D model - Other - 206-5-7
click to zoom

206-5 Details

  • Manufacturer Part Number:

    206-5

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS COMPLIANT

  • Reach Compliance Code:

    Compliant

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.50.90.65

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    CTS Corporation

  • YTEOL:

    6.3

  • Body Breadth:

    9.78 mm

  • Body Height:

    7.6 mm

  • Body Length or Diameter:

    14.88 mm

  • Contact Current(DC)-Max:

    0.05 A

  • Contact (DC) Max Rating R Load:

    .05A@24VDC

  • Contact Voltage(DC)-Max:

    24 V

  • Electrical Life:

    10000 Cycle(s)

  • JESD-609 Code:

    e4

  • Mounting Feature:

    THROUGH HOLE-STRAIGHT

  • Number of Switch Sections:

    5

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -55 °C

  • PCB Hole Count:

    10

  • Packing Method:

    ANTI-STATIC TUBE

  • Surface Mount:

    NO

  • Switch Action:

    LATCHED

  • Switch Function:

    SPST

  • Switch Type:

    SLIDE DIP SWITCH

  • Terminal Finish:

    Gold (Au)

  • Termination Type:

    SOLDER

206-5 Frequently Asked Questions (FAQs)

  • A symmetrical layout with a solid ground plane and minimal signal trace length is recommended. Keep the input and output traces separate and avoid crossing them.
  • Use a thermally conductive material for the PCB, ensure good airflow, and consider using a heat sink if the device will be operating near the maximum temperature rating.
  • Power up the VCC pin first, followed by the VDD pin. This ensures proper internal biasing and prevents damage to the device.
  • Use a logic analyzer or oscilloscope to monitor the input and output signals. Check for proper power supply voltage, signal integrity, and ensure the device is properly soldered and seated.
  • Yes, but ensure you follow the recommended design and manufacturing guidelines. Perform thorough testing and validation to ensure the device meets the required reliability and safety standards.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

206-5 Overview

Use the download button to access the 206-5 schematic symbol, PCB footprint, and 3D model.
