2181AL08-U - THAT CORPORATION

2181AL08-U Details

• Manufacturer Part Number:

  2181AL08-U

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  ROHS COMPLIANT, PLASTIC, SIP-8

• HTS Code:

  8542.39.00.60

• Manufacturer:

  THAT Corporation

• Additional Feature:

  SEATED HGT-CALCULATED

• Consumer IC Type:

  CONSUMER CIRCUIT

• JESD-30 Code:

  R-PSIP-T8

• JESD-609 Code:

  e4

• Length:

  19.5 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Seated Height-Max:

  7.2 mm

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  4 V

• Surface Mount:

  NO

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  NICKEL PALLADIUM GOLD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Width:

  2.8 mm
