26-01-3142 - Molex

26-01-3142 Details

• Manufacturer Part Number:

  26-01-3142

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mexico

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  17 Weeks

• Manufacturer:

  Molex

• YTEOL:

  8

• Additional Feature:

  RATED CURRENT(POWER): 13A

• Body Breadth:

  0.38 inch

• Body Depth:

  0.785 inch

• Body Length:

  0.38 inch

• Connector Type:

  RECTANGULAR POWER CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  Matte Tin (Sn)

• Contact Gender:

  FEMALE

• Contact Material:

  BRASS

• Contact Style:

  SQ PIN-SKT

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulator Material:

  POLYAMIDE66

• JESD-609 Code:

  e3

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Type:

  BOARD

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Reference Standard:

  CSA; UL

• Termination Type:

  SOLDER

• Total Number of Contacts:

  4

• UL Flammability Code:

  94V-2
