The recommended torque value is 0.5-1.5 Nm (4-12 in-lbs) for the screw terminals, but it's always best to consult the specific application and 3M's guidelines for the specific connector.
Yes, the 268-5401-00-1102JH connector is designed to withstand vibrations and is suitable for use in applications with moderate to high vibration levels. However, it's essential to ensure proper mounting and securement to prevent damage or disconnection.
The 268-5401-00-1102JH connector has a IP67 rating, making it suitable for outdoor use and exposure to harsh environmental conditions, including dust, water, and extreme temperatures. However, it's crucial to follow proper installation and sealing guidelines to maintain the IP67 rating.
The 268-5401-00-1102JH connector has an operating temperature range of -40°C to 125°C (-40°F to 257°F), making it suitable for use in a wide range of applications, including those with high-temperature requirements.
The 268-5401-00-1102JH connector is designed for use with 20-24 AWG wire. While it may be possible to use it with other wire gauges or types, it's essential to consult 3M's guidelines and ensure compatibility to avoid damage or performance issues.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
268-5401-00-1102JH Overview
Use the download button to access the 268-5401-00-1102JH schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like 268-5,
or try a keyword search, such as Sockets and Chip Carriers
