2D15-P6 - Advanced Energy

2D15-P6 Details

• Manufacturer Part Number:

  2D15-P6

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Advanced Energy Industries Inc

• YTEOL:

  6

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Control Mode:

  VOLTAGE-MODE

• Input Voltage-Max:

  16.5 V

• Input Voltage-Min:

  13.5 V

• Input Voltage-Nom:

  15 V

• JESD-30 Code:

  R-MXMA-T8

• Length:

  63.5 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  65 °C

• Operating Temperature-Min:

  -10 °C

• Output Current-Max:

  3 A

• Output Voltage-Max:

  2000 V

• Package Body Material:

  METAL

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OUTPUT OVER CURRENT

• Seated Height-Max:

  17.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  6 W

• Trim/Adjustable Output:

  YES

• Width:

  44 mm
