2DA1213YQ-13 - Diodes Incorporated

2DA1213YQ-13 Details

• Manufacturer Part Number:

  2DA1213YQ-13

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SOT-89, 3 PIN

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Factory Lead Time:

  12 Weeks

• Date Of Intro:

  2018-11-30

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  7

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  2 A

• Collector-Base Capacitance-Max:

  17 pF

• Collector-Emitter Voltage-Max:

  50 V

• Configuration:

  SINGLE

• DC Current Gain-Min (hFE):

  20

• JESD-30 Code:

  R-PSSO-F3

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  PNP

• Power Dissipation-Max (Abs):

  1 W

• Reference Standard:

  AEC-Q101; IATF 16949; MIL-STD-202

• Surface Mount:

  YES

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  FLAT

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  160 MHz

• VCEsat-Max:

  0.5 V
