Infineon recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended.
Infineon recommends following the thermal design guidelines, using a heat sink if necessary, and ensuring good airflow around the device. Additionally, consider using a thermistor or thermocouple to monitor the device temperature.
Infineon recommends a peak reflow temperature of 260°C, with a maximum time above 217°C of 30 seconds. The device is also compatible with lead-free soldering processes.
Infineon recommends storing the devices in their original packaging, away from direct sunlight and moisture. Avoid bending or flexing the leads, and handle the devices by the body, not the leads.
Infineon recommends following standard ESD precautions, such as using an ESD wrist strap or mat, and handling the devices in a static-protected environment.
