2SA1576U3T106 - ROHM Semiconductor

2SA1576U3T106 Details

• Manufacturer Part Number:

  2SA1576U3T106

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SC-70, SOT-323, 3 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  10

• Collector Current-Max (IC):

  0.15 A

• Collector-Base Capacitance-Max:

  5 pF

• Collector-Emitter Voltage-Max:

  50 V

• Configuration:

  SINGLE

• DC Current Gain-Min (hFE):

  120

• JESD-30 Code:

  R-PDSO-G3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, 7 INCH

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  PNP

• Power Dissipation-Max (Abs):

  0.2 W

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  AMPLIFIER

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  140 MHz

• VCEsat-Max:

  0.5 V
