2SJ109 - Toshiba

2SJ109 Details

• Manufacturer Part Number:

  2SJ109

• Part Life Cycle Code:

  Active Unconfirmed

• Package Description:

  2-10M1A, 7 PIN

• Pin Count:

  7

• ECCN Code:

  EAR99

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  2

• Additional Feature:

  LOW NOISE

• Configuration:

  SEPARATE, 2 ELEMENTS

• FET Technology:

  JUNCTION

• JESD-30 Code:

  R-PZIP-T7

• JESD-609 Code:

  e0

• Number of Elements:

  2

• Number of Terminals:

  7

• Operating Mode:

  DEPLETION MODE

• Operating Temperature-Max:

  125 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Polarity/Channel Type:

  P-CHANNEL

• Power Dissipation-Max (Abs):

  0.4 W

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  ZIG-ZAG

• Transistor Application:

  AMPLIFIER

• Transistor Element Material:

  SILICON
