302W2CSXX56N40X - CONEC

302W2CSXX56N40X Details

• Manufacturer Part Number:

  302W2CSXX56N40X

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Conec Corporation

• YTEOL:

  9

• Body Breadth:

  0.509 inch

• Body Depth:

  0.211 inch

• Body Length:

  1.228 inch

• Body/Shell Style:

  SOCKET

• Connector Type:

  D SUBMINIATURE CONNECTOR

• Contact Arrangement:

  S0C2

• Contact Finish Mating:

  AU ON NI

• Contact Gender:

  FEMALE

• Contact Material:

  COPPER ALLOY

• Contact Pattern:

  STAGGERED

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  750VAC V

• Empty Shell:

  YES

• Filter Feature:

  NO

• Insertion Force-Max:

  7 N

• Insulation Resistance:

  5000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  PBT-POLYESTER

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Option 1:

  #4-40

• Mounting Option 2:

  THREADED

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Rated Current (Signal):

  20 A

• Reference Standard:

  UL

• Shell Finish:

  TIN

• Shell Material:

  STEEL

• Shell Size:

  1/E

• Termination Type:

  SOLDER

• Total Number of Contacts:

  2

• UL Flammability Code:

  94V-0

• Withdrawl Force-Min:

  7 N
