31-5329-52RFX - Amphenol

31-5329-52RFX Details

• Manufacturer Part Number:

  31-5329-52RFX

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  7.55

• Additional Feature:

  INSERTION LOSS MAX AT 3 GHZ

• Body Depth:

  0.655 inch

• Body/Shell Style:

  RECEPTACLE

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF BNC CONNECTOR

• Contact Finish Mating:

  GOLD (5)

• Contact Finish Termination:

  GOLD (5)

• Contact Gender:

  FEMALE

• Contact Style:

  COAX

• Coupling Type:

  BAYONET

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  1500VAC V

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Loss:

  0.2 dB

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE-POLYESTER

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Frequency-Max:

  4 GHz

• Operating Temperature-Max:

  165 °C

• Operating Temperature-Min:

  -65 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Shell Finish:

  NICKEL

• Shell Material:

  BRASS

• Terminal Length:

  0.176 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.3
