342-10-164-00-592000 - Mill-Max

Description: Board Stacking Pin Headerv.018" (0,46mm) Pin Head, Positions

Download 342-10-164-00-592000 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
342-10-164-00-592000 - Mill-Max PCB footprint - Header, Vertical - Header, Vertical - 342-10-164-00-592000
click to zoom
3D Models
342-10-164-00-592000 - Mill-Max  - 3D model - Header, Vertical - 342-10-164-00-592000
click to zoom

342-10-164-00-592000 Details

  • Manufacturer Part Number:

    342-10-164-00-592000

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS COMPLIANT

  • Country Of Origin:

    USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.90.40.00

  • Manufacturer:

    Mill-Max Mfg Corp

  • YTEOL:

    7

  • Body Breadth:

    0.1 inch

  • Body Depth:

    0.335 inch

  • Body Length:

    6.4 inch

  • Contact Configuration:

    RECTANGLE

  • Contact Finish Mating:

    NOT APPLICABLE

  • Contact Finish Termination:

    Gold (Au) - with Nickel (Ni) barrier

  • Contact Material:

    NOT APPLICABLE

  • Contact Style:

    RND PIN-SKT

  • Current Rating:

    3 A

  • Device Socket Type:

    IC SOCKET

  • Device Type Used On:

    SIP64

  • Housing Material:

    POLYETHYLENE

  • JESD-609 Code:

    e4

  • Mating Contact Pitch:

    0.1 inch

  • Mounting Style:

    STRAIGHT

  • Number of Contacts:

    64

  • PCB Contact Pattern:

    RECTANGULAR

  • PCB Contact Row Spacing:

    0.003937007874015749 mm

  • Terminal Pitch:

    2.54 mm

  • Termination Type:

    SOLDER

342-10-164-00-592000 Frequently Asked Questions (FAQs)

  • The recommended torque for the screw terminals is typically between 0.5 to 1.5 in-lbs (0.056 to 0.169 Nm), but it's best to consult the manufacturer's application notes or contact their technical support for specific guidance.
  • Yes, the contacts are gold-plated, and the typical plating thickness is 0.000015 inches (0.38 microns) to 0.000030 inches (0.76 microns) per MIL-G-45204, but it's best to verify with the manufacturer for specific information.
  • The operating temperature range for the 342-10-164-00-592000 connector is typically -55°C to 125°C, but it's essential to check the manufacturer's specifications and application notes for any specific temperature-related limitations.
  • The 342-10-164-00-592000 connector is designed to meet the requirements of MIL-STD-202, but it's recommended to consult the manufacturer's application notes and perform additional testing to ensure the connector meets the specific vibration and shock requirements of your application.
  • The 342-10-164-00-592000 connector is designed to meet the requirements of MIL-STD-202, which includes humidity and moisture testing. However, it's essential to follow proper sealing and potting procedures to ensure the connector's reliability in humid or wet environments.
