412H-12 - Teledyne Technologies

412H-12 Details

• Manufacturer Part Number:

  412H-12

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  Teledyne Technologies Inc

• YTEOL:

  7.3

• Body Height:

  6.86 mm

• Body Length or Diameter:

  9.4 mm

• Coil Current(DC)-Max:

  0.038 A

• Coil Operate Voltage(DC):

  11.9 V

• Coil Power:

  450 mW

• Coil Release Voltage(DC):

  0.41 V

• Coil Resistance:

  390 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  .25A@115VAC

• Contact Current(AC)-Max:

  0.25 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@28VDC

• Contact Voltage(AC)-Max:

  115 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  3.5 ms

• Operating Temperature-Max:

  200 °C

• Operating Temperature-Min:

  -65 °C

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  3.5 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Terminal Finish:

  GOLD

• Termination Type:

  SOLDER
