4816P-1-750LF - Bourns

4816P-1-750LF Details

• Manufacturer Part Number:

  4816P-1-750LF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SOM-16

• Reach Compliance Code:

  Not Compliant

• Country Of Origin:

  Costa Rica

• ECCN Code:

  EAR99

• HTS Code:

  8533.21.00.20

• Factory Lead Time:

  7 Weeks

• Manufacturer:

  Bourns Inc

• YTEOL:

  7

• Construction:

  Rectangular

• Element Power Dissipation:

  0.16 W

• First Element Resistance:

  75 Ω

• JESD-609 Code:

  e2

• Mounting Feature:

  SURFACE MOUNT

• Network Type:

  ISOLATED

• Number of Elements:

  1

• Number of Functions:

  8

• Number of Terminals:

  16

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Height:

  2.03 mm

• Package Length:

  5.59 mm

• Package Style:

  SOIC

• Package Width:

  11.18 mm

• Packing Method:

  TR, 13 INCH

• Rated Power Dissipation (P):

  1.28 W

• Rated Temperature:

  70 °C

• Resistance:

  75 Ω

• Resistor Type:

  ARRAY/NETWORK RESISTOR

• Second/Last Element Resistance:

  75 Ω

• Size Code:

  2244

• Surface Mount:

  YES

• Technology:

  METAL GLAZE/THICK FILM

• Temperature Coefficient:

  100 ppm/°C

• Temperature Coefficient Tracking:

  50 ppm/°C

• Terminal Finish:

  TIN COPPER

• Terminal Shape:

  GULL WING

• Tolerance:

  2%

• Working Voltage:

  50 V
