5227699-2 - TE Connectivity

5227699-2 Details

• Manufacturer Part Number:

  5227699-2

• Brand Name:

  AMP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Factory Lead Time:

  20 Weeks

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.55

• Additional Feature:

  VSWR MAX AT 3 GHZ

• Body Depth:

  0.625 inch

• Body/Shell Style:

  JACK

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF BNC CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT APPLICABLE

• Contact Style:

  COAX

• Coupling Type:

  BAYONET

• DIN Conformance:

  NO

• Durability:

  500 Cycles

• EMI Shielded:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Loss:

  0.2 dB

• Insulation Resistance:

  5000000000 Ω

• Insulator Material:

  GLASS FILLED POLYBUTYLENE TEREPHTHALATE

• MIL Conformance:

  NO

• Mains Connector Rating:

  115/230VAC

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  PANEL

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Operating Frequency-Max:

  4 GHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  YES

• Shell Finish:

  NICKEL

• Shell Material:

  ZINC ALLOY

• Terminal Length:

  0.25 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  1

• VSWR:

  1.3
