530PB45M1584DGR - Skyworks

530PB45M1584DGR Details

• Manufacturer Part Number:

  530PB45M1584DGR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Manufacturer:

  Skyworks Solutions Inc

• YTEOL:

  6.38

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  20%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  45.1584 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  CMOS

• Output Load:

  15 pF

• Output Low Current-Max:

  32 mA

• Package Equivalence Code:

  DILCC6,.2

• Physical Dimension:

  7.0mm x 5.0mm x 1.8mm

• Screening Level:

  MIL-STD-883

• Supply Current-Max:

  88 mA

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier
